"GO-NO GO" snap gauges.Rigid body in stabilized special steel C10.Case-hardened and tempered calibration sectors hardness>62 HRC.Lapped surfaces.Range Ø 3-100mm.
20 other products in the same category:
Smooth plugs differential P-NP with GO side in carbide.
Measuring range: from Ø8 to Ø60 mm
On request, GO and NO GO side in hard metal.
Precision measuring pins set. Supplied in case with handles.
Toll +/- 0,002Single with special length and/or diameter upon requirement.
Set of tungsten carbide parallel gauge blocks. Tungsten carbide has the following advantages over steel: a much lower expansion coefficient with grater stability even at temperatures other than the reference; greater...
Carbide groove diameter checking snap gauge.
Rigid body in steel hardened and toughened duly marked GO-NOGO sizes.
From ø 5 mm to ø 60 mm.
Cod. 01 Set of holder accessories.
It contains 12 pieces which allow combinations of various gauge blocks.Supplied in case.From Cod. 02 single pieces.
Digital zeroing bench suitable for zeroing bore gauges, calipers, micrometers, comparative calipers, etc...Reading of the values on the display.Reading 0.001Rows high precision optics.Movement of measuring device on...
Long gauge blocks. Set of 8 pieces long gauge blocks in non-deformable high quality steel. Supplied in case. Serial number on each block. Manufactured as per DIN 861. Set composition: 125 – 150 – 175 – 200 – 250 – 300...
Thread ring gauges in high wear-resistant steel-chrome alloy.Core-hardened, tempered and stabilised.Normally constructed gauges for the following thread types: Metric, Withworth, Cylindrical gas, Conical gas, Acme,...
Composition of parallel gauge blocks in top-quality non-deformable steel.Supplied in case, serial number on each block. Manufactured as per DIN 861.Three different grades are available:
Gr. 0: suitable for metrology...
Thread plug gauges in high wear-resistant steel-chrome alloy.Core hardened, tempered and stabilised.Normally costructed gauges for the following thread types: Metric, Withworth, Cylindrical gas,Tape gas, Acme,...
Set of exceptionally pure ceramic zircon parallel gauge blocks. The physical and mechanical properties of ceramic zircon offer the following advantages: an expansion coefficient similar to the steel; high thermal...
Carabide double ended snap gauges.
Rigid body in steel hardened and toughened duly marked GO-NOGO sizes.
Guaging jaw tips tungsten carabide.
From ø 6 mm to ø 60 mm.
Progressive "GO-NO GO" limit snap gauges.Rigid body in stabilized special steel C10.Case-hardened and tempered calibration sectors hardness>62 HRC.Lapped surfaces.Range Ø 3-100mm.
Composition of parallel gauge blocks in top-quality non-deformable steel.Supplied in case, serial number on each block.Manufactured as per DIN 861.Three different grades are available:
Gr. 0: suitable for metrology...
These reversible type plug gauges, due to their modular composition, last twice as long as the normal plug gagues, since their calibrated parts can be inverted in case of wear.Furthermore, it is possible to set the...
Flat plug gauges in “Go-No Go” pairs.Rigid body in stabilised special steel.The calibrating sections are case-hardened and tempered.
From ø 110 to ø 204 mm.
Smooth reversible carbide plugs. Measurement range: Ø1 - Ø8 mm.Aluminium handle (with brass fittings to fix the contacts)"L" PASS side length: 25 mm
Standard lenght 50 mm. Tolerance ±0,002 Rockwell hardness ≥58.
Cylindrical pinscalibrated from Ø1 to Ø10 mm in hard metal.Construction tolerance: ±0.001 mm Roughness: <0.025 µRa Roundness: <0,0005 mmTaper: <0,001 mmLength: 50 mm
Composition of parallel gauge blocks in top-quality non-deformable steel.Supplied in case, serial number on each block. Manufactured as per DIN 861. Three different grades are available:
Gr. 0: suitable for...
