Set of tungsten carbide parallel gauge blocks. Tungsten carbide has the following advantages over steel: a much lower expansion coefficient with grater stability even at temperatures other than the reference; greater...
|
CODE
|
RANGE
(mm)
|
STEP
(mm)
|
NR.
|
|
00
|
0,5-1,00
|
0,01
|
51 |
|
01
|
1,01-2,00 | 0,01 |
100
|
|
02
|
2,01-3,00 | 0,01 |
100
|
|
03
|
3,01-4,00 | 0,01 |
100
|
|
04
|
4,01-5,00 | 0,01 |
100
|
|
05
|
5,01-6,00 | 0,01 |
100
|
|
06
|
6,01-7,00 | 0,01 |
100
|
|
07
|
7,01-8,00 | 0,01 |
100
|
|
08
|
8,01-9,00 | 0,01 |
100
|
|
09
|
9,01-10,00 | 0,01 |
100
|
|
10
|
1,00-8,00 | 0,05 | 141 |
|
11
|
8,00-12,00 | 0,05 |
81
|
|
12
|
1,00-10,00 | 0,1 |
91
|
|
13
|
10,00-16,00 | 0,1 |
61
|
|
14
|
16,00-20,00 | 0,1 |
41
|
|
15
|
1,00-20,00
|
0,5
|
39 |
