HIGH QUALITY/ACCURACY OUTSIDE MICROMETER WUTH DISCS 164
High quality/accuracy outside micrometer with discs. Casting painted arc heat-insulated. Thimble ( ø 19 mm x step 0,5 – ø 25 mm x step 1) chromed and etched by laser for a clear and long lasting. Friction on the thimble and locking lever. Screw completely hardened and ground with specific working systems to assure the max accuracy for a long time. Serial number. Manufactured as per DIN 863. Supplied in a box with key, setting rod not included. Upon requirement range over till the 400 mm.
Reference:
ART.0164
|
CODE
|
READING
(mm)
|
RANGE
(mm)
|
DISC Ø
(mm)
|
1 ROUND OF THE TIMBLE (mm)
|
|
01
|
0,01
|
0-25
|
25
|
0,05
|
|
02
|
0,01
|
25-50
|
25
|
0,05
|
|
03
|
0,01
|
50-75
|
25
|
0,05
|
|
04
|
0,01
|
75-100
|
25
|
0,05
|
|
05
|
0,01
|
0-25
|
30
|
1
|
|
06
|
0,01
|
25-50
|
30
|
1
|
|
07
|
0,01
|
50-75
|
30
|
1
|
|
08
|
0,01
|
75-100
|
30
|
1
|
|
09
|
SETTING GAUGE 25 mm
|
|||
|
10
|
SETTING GAUGE 50 mm
|
|||
|
11
|
SETTING GAUGE 75 mm
|
|||
