G25 pearlitic cast iron square.Compact and stabilized structure.Fine planed work surfaces.
PDF TAB
|
CODE
|
READING
(mm)
|
Ø RANGE
(mm)
|
SECTION
(mm)
|
|
01
|
0,01
|
15-115
|
8x0,1
|
|
02
|
0,01
|
100-220
|
11x0,1
|
|
03
|
0,01
|
100-300
|
11x0,1
|
|
04
|
0,01
|
28-300
|
13x0,25
|
|
05
|
0,01
|
300-600
|
13x0,25
|
|
06
|
0,01
|
600-900
|
13x0,25
|
|
07
|
0,01
|
900-1200
|
13x0,25
|
|
08
|
0,01
|
1200-1500
|
13x0,25
|
|
09
|
0,01
|
1500-1800
|
13x0,25
|
|
10
|
0,01
|
1800-2100
|
13x0,25
|
|
11
|
0,01
|
2100-2400
|
13x0,25
|
|
12
|
0,01
|
2400-2700
|
13x0,25
|
|
13
|
0,01
|
2700-3000
|
13x0,25
|
